Sensor Diaphragms
LSR pressure-sensing diaphragms with ±1% linearity repeatability across -40 °C to 200 °C.
Application Overview
Sensor diaphragms translate pressure into signal — stiffness must be identical from part 1 to part 1,000,000. We LSR-injection mold diaphragms with wafer-thin sensing zones and rigid mounting flanges in one shot, eliminating assembly drift. Compounds are formulated for low hysteresis and resistance to media such as brake fluid, diesel and glycol.
Technical Standards
- ✓IATF 16949-aligned manufacturing; PPAP Level 3 documentation on request
- ✓Media compatibility: brake fluid, diesel, glycol coolant immersion tested
- ✓Operating envelope -40 °C to +200 °C validated
- ✓MSA/SPC data packages for OEM APQP processes
Manufacturing Process
Diaphragms are LSR injection molded in zero-flash tools with optical-grade cavity finishes.
- Sensing membrane thickness controlled to ±0.01 mm by insert precision
- Rigid flange and soft membrane co-molded — no bonding drift
- Post-cure cycle stabilized to lock in modulus
- Lot-controlled pigment batches for traceability
Quality Inspection
- 🔍100% visual inspection (flash, short-shot, contamination) before packing
- 🔍Dimensional verification against approved drawing; FAI report on first shipment and after any tooling change
- 🔍Hardness per ASTM D2240 (Shore A) on every batch
- 🔍Lot traceability: material batch, cure records and operator logged for every carton
- 🔍Membrane thickness verification on FAI and tool-change lots
- 🔍Deflection/stiffness sampling test per lot
- 🔍Compression set per ASTM D395 for sealing flanges
- 🔍100% visual under ring-light for membrane defects
After-sales & Support
Every order ships with a Certificate of Conformance, First Article Inspection report and lot traceability records.
- Warranty: 12 months against material and workmanship defects
- Response: engineering reply within 24 hours, 8D report for confirmed quality issues
- Remedy: free replacement or credit for non-conforming batches; expedited re-shipment at our cost
- Support: free design-for-manufacturing review, material selection advice and sample policy for evaluation
- Recall readiness: full batch traceability enables targeted containment within 48 hours
