Conductive Keypads
Silicone keypads with carbon or gold pills โ 1M+ actuation life and consistent tactile force.
Application Overview
A medical or industrial keypad must click the same on day 1,000 as on day 1. We mold silicone keypads with laser-aligned conductive pills (carbon or gold), web geometries tuned to your actuation-force curve, and printed or laser-etched legends. Life-tested to 1-5 million cycles depending on the stack-up.
Technical Standards
- โActuation life 1M-5M cycles validated per stack-up
- โContact resistance โค 200 ฮฉ (carbon pill) / โค 5 ฮฉ (gold pill)
- โASTM D257 static resistivity verification on conductive elements
- โRoHS / REACH compliant; biocompatible grades for medical housings
Manufacturing Process
Keypads are compression or LSR injection molded with pills inserted in-mold or post-cure assembled.
- Web-thickness FEAs tune actuation force and snap-ratio to your feel spec
- Conductive pills positioned by nesting fixtures to ยฑ0.05 mm
- Epoxy or laser legends applied after post-cure
- Die-cut adhesive backing option for assembly
Quality Inspection
- ๐100% visual inspection (flash, short-shot, contamination) before packing
- ๐Dimensional verification against approved drawing; FAI report on first shipment and after any tooling change
- ๐Hardness per ASTM D2240 (Shore A) on every batch
- ๐Lot traceability: material batch, cure records and operator logged for every carton
- ๐Actuation force / travel sampling per lot (force-displacement curve)
- ๐Contact resistance sampling per lot
- ๐Key life sampling (1M cycles) on validation lots
- ๐Legend adhesion cross-hatch test on printed parts
After-sales & Support
Every order ships with a Certificate of Conformance, First Article Inspection report and lot traceability records.
- Warranty: 12 months against material and workmanship defects
- Response: engineering reply within 24 hours, 8D report for confirmed quality issues
- Remedy: free replacement or credit for non-conforming batches; expedited re-shipment at our cost
- Support: free design-for-manufacturing review, material selection advice and sample policy for evaluation
- Recall readiness: full batch traceability enables targeted containment within 48 hours
