Extrusion Dies
Silicone extrusion dies with swell-compensated profiles — from your drawing to stable output fast.
Application Overview
Silicone swells 20-40% on exit, so a die that cuts the finished profile dimensionally will never run stable. We design extrusion dies with swell compensation calculated from compound rheology, then prove them on our own extrusion lines until the profile holds tolerance continuously — you receive a die that runs, not a die that needs debugging.
Technical Standards
- ✓Die steel: hardened tool steel, polished flow channels
- ✓Swell-compensated profile design from compound rheology data
- ✓Profile tolerance: ±0.05 mm on critical dimensions (typical)
- ✓Die life guarantee with re-polishing service
Manufacturing Process
Profile CAD → swell simulation → die machining → prove-out on our extrusion lines.
- Flow-channel polish for laminar, streak-free extrusion
- Iterative prove-out cuts: dimension stabilized on our line before shipping
- Multi-lumen and complex hollow profiles supported
- Spare die sets available for high-runner profiles
Quality Inspection
- 🔍Flow channel dimensional report before polishing
- 🔍Prove-out run: continuous-profile dimensional records
- 🔍Surface finish verification of flow channels
- 🔍Prove-out sample coils shipped with die qualification
After-sales & Support
Every order ships with a Certificate of Conformance, First Article Inspection report and lot traceability records.
- Warranty: 12 months against material and workmanship defects
- Response: engineering reply within 24 hours, 8D report for confirmed quality issues
- Remedy: free replacement or credit for non-conforming batches; expedited re-shipment at our cost
- Support: free design-for-manufacturing review, material selection advice and sample policy for evaluation
- Recall readiness: full batch traceability enables targeted containment within 48 hours
